12.7 detroit upgrades

Discussion in 'Trucks [ Eighteen Wheelers ]' started by prerunner404, Jun 21, 2016.

  1. benjamin260_6

    benjamin260_6 Medium Load Member

    412
    444
    Aug 8, 2012
    Ontario, Canada
    0
    As stated by swan, the E indicates that it's a factory reman and unfortunately it's too new for the program I have. I can make an educated guess based on the model number though

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. '07 KW w/53' Conestoga

    '07 KW w/53' Conestoga Medium Load Member

    322
    281
    Sep 28, 2015
    0
    Thanks, I didnt know that, makes sense...wouldn't have a brand new Pre-EGR motor sitting around still 10 yrs later, or, you wouldn't expect to.

    So, because it reman, there's no way to tell what injectors it has without opening it up?

    Vampire and jamespmack Thank this.
  4. benjamin260_6

    benjamin260_6 Medium Load Member

    412
    444
    Aug 8, 2012
    Ontario, Canada
    0
    Any Detroit dealer can run your serial number, my program is just too old. But like I said, if you give me your model number I can make an educated guess. Eg. A BK will most likely have 7650 injectors, 309 cam, 16.5:1 pistons and will have piston cooling nozzles

  5. '07 KW w/53' Conestoga

    '07 KW w/53' Conestoga Medium Load Member

    322
    281
    Sep 28, 2015
    0
    6067GK60

    jamespmack Thanks this.
  6. benjamin260_6

    benjamin260_6 Medium Load Member

    412
    444
    Aug 8, 2012
    Ontario, Canada
    0
    If it's a 500 it's probably got 5915 injectors and a 1681 cam. If it's a 430/470 it probably has 5575 injectors and a 3564 cam

  7. heavyhaulerss

    heavyhaulerss Road Train Member

    3,714
    2,017
    Dec 23, 2009
    AL/TN BORDER
    0
    You cam have the cold settings changed in the e.c.m. so you don't have the smoke when cold.

  8. ChicagoJohn

    ChicagoJohn Road Train Member

    2,340
    2,662
    Jan 14, 2016
    Chicago
    0
    I didn't even know that was a option. I'll look into it thanks.

  9. '07 KW w/53' Conestoga

    '07 KW w/53' Conestoga Medium Load Member

    322
    281
    Sep 28, 2015
    0
    Thank you so much for the great info!

    I have a print out from the Dr in Effingham. IL...

    It says it was a 430...I'm pretty sure they said it was 430 straight across, no difference on cruise versus foot. Is that same injectors and cam? Is there a limit what you can or suggestions on what I should put in if and when it's time to change?

    The Dr set it up so it was bumped to 550 hp and 1,850 torque.

    I don't mind doing things if there is financial benefit...or if it was seriously lacking something...which is what lead me to the Dr's office after I bought it in the first place.

    Right now, it seems to be running real good.

    OK, now I have gone off frantically in search of a piece of wood. LOL!

    Willmann30 Thanks this.
  10. '07 KW w/53' Conestoga

    '07 KW w/53' Conestoga Medium Load Member

    322
    281
    Sep 28, 2015
    0
    When you say "changed" what does that mean? Set it up so it uses less fuel at lower temp? I was told by a Detroit mechanic last year it might be a cold temp sensor too...or maybe he said air sensor...I don't recall. I didn't mess with it, not yet at least. That is further down on my laundry list of things to do!!!

  11. benjamin260_6

    benjamin260_6 Medium Load Member

    412
    444
    Aug 8, 2012
    Ontario, Canada
    0
    You could upgrade to the 5915s, that would take you to about 580 with your current ecm setting. A set of 7014s would probably put you 625+. Being a GK, it was never drilled for oil cooling nozzles so going much over 600 is risky unless you really pay attention to your gauges. I always recommend getting it breathing right before getting a lot of fuel in the. High flow manifold, muffler, air filters and an upgraded turbo. Usually by then with a tune you won't be worrying about bigger injectors.

    Since you brought up it being a straight 430, I just want to add that it really doesn't make a lot of difference if it's set to 430 or 470 or even 430/470. They achieve the 470 by giving it just a little extra fuel, usually between 1800 and 2100rpm. Because both setting are 1550tq, they have the same torque curve up to that point so they pull the exact same. You have to really rev it to get any noticeable difference and most people don't.
