crankshaft end play??????????

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by benny906, May 25, 2019.

  1. May 25, 2019 #1
    benny906

    benny906 Bobtail Member

    20
    12
    Nov 3, 2017
    0
    1997 3406E std bearings and thrust washers.
    had crank polished, they say it stayed at std size.
    installed new bearings and thrust washers.
    measured end play its at .0117, what is the specs for this supposed to be??
    thanks for helping

    benny906, May 25, 2019
    benny906, May 25, 2019
    #1
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. May 25, 2019 #2
    wore out

    wore out Numbered Classic

    14,342
    173,953
    Jun 5, 2013
    CHASIN THE DEVIL'S HERD
    0

    wore out, May 25, 2019
    wore out, May 25, 2019
    #2
    spsauerland, Heavyd, Humblepie and 3 others Thank this.
  4. May 25, 2019 #3
    benny906

    benny906 Bobtail Member

    20
    12
    Nov 3, 2017
    0
    I dont have the correct manual! I have one for a c15 accert!
    Is anything interchangeable between the 2 Manual wise?
    If not I will go buy one?

    benny906, May 25, 2019
    benny906, May 25, 2019
    #3
  5. May 25, 2019 #4
    wore out

    wore out Numbered Classic

    14,342
    173,953
    Jun 5, 2013
    CHASIN THE DEVIL'S HERD
    0
    I would want the right one, lots of similarities but some differences too. Especially with rod bolts and torque

    wore out, May 25, 2019
    wore out, May 25, 2019
    #4
    Rideandrepair, Heavyd and benny906 Thank this.
  7. May 25, 2019 #5
    benny906

    benny906 Bobtail Member

    20
    12
    Nov 3, 2017
    0
    I will go buy one!
    Its alot cheaper than the motor!‍♂️

    benny906, May 25, 2019
    benny906, May 25, 2019
    #5
    xsetra, Rideandrepair, Heavyd and 1 other person Thank this.
  8. May 25, 2019 #6
    benny906

    benny906 Bobtail Member

    20
    12
    Nov 3, 2017
    0
    Turns out my end play is .0117!
    My new dial indicator reads out to 4 numbers instead of 3!
    Feel stupid! But I know it's good though!

    benny906, May 25, 2019
    benny906, May 25, 2019
    #6
    Rideandrepair, BoxCarKidd, Heavyd and 1 other person Thank this.
