Shifting an 8spd

Discussion in 'Ask An Owner Operator' started by Boosted_SC300, Jun 8, 2020.

  1. Boosted_SC300

    Boosted_SC300 Light Load Member

    84
    88
    Feb 27, 2018
    0
    Ok maybe its just me but how tf do you shift an 8spd transmission without grinding to 5th or down to 4th!? I could shift flawlessly in my 13spd but for the 8's ive always had a hard time even floating them. Anyone know the "sweet spot"
    since im stuck In this Volvo VNL for a while? i believe its a fuller
    Thanks!

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Brettj3876

    Brettj3876 Road Train Member

    11,257
    54,039
    Nov 18, 2014
    Land of local
    0
    Same shift pattern as 13/18. Your talking about a 9 speed or 8ll?

    Bean Jr. and singlescrewshaker Thank this.
  4. Badmon

    Badmon Heavy Load Member

    806
    1,502
    Oct 6, 2014
    Deep south
    0
    Bet he's talking 8ll i had the same issue til I figured out the ll switch wasnt for going from the high side to low or vice versa

    650cat425 Thanks this.
  5. Bean Jr.

    Bean Jr. Road Train Member

    5,338
    9,357
    Mar 30, 2014
    0
    Anytime you switch transmissions, it takes time to get used to the rhythm of the new transmission. When going from a 13 to an 8 speed you're going to need to wind it up more, and shift slower. The engine will need to lose more RPMs, and that takes more time.

    Last edited: Jun 9, 2020
    Reason for edit: Poor grammar!
  6. Brettj3876

    Brettj3876 Road Train Member

    11,257
    54,039
    Nov 18, 2014
    Land of local
    0
    Find out what your speed is in 4th at about 1600 rpm and take a mental note so you know pretty much where you need to be. I usually go 5th to 3rd and I know 15mph it will slide right in at 1600

    Bean Jr. and PE_T Thank this.
  7. PE_T

    PE_T Road Train Member

    Maybe I’m wrong, but the so called 8-speed is technically a 9-speed when you count the (LO) granny gear.


    Attached Files:

    Brettj3876 and snowwy Thank this.
  8. Boosted_SC300

    Boosted_SC300 Light Load Member

    84
    88
    Feb 27, 2018
    0
    I know shift pattern is the same but i always grind gears going from 4th to 5th or downshifting from 5th to 4th.
    But thru testing with RPM and MPH to see if i can get it, this past day and a half ive concluded that the 8spd sucks and im glad this torture is almost over lol. For whatever reason i just cant make that transition ‍♀️

  9. Boosted_SC300

    Boosted_SC300 Light Load Member

    84
    88
    Feb 27, 2018
    0
    1 2 3 4 switch it to hi 5 6 7 8.
    But yeah youre right its a 9 i just dont count the lo since i dont need it haha

    PE_T Thanks this.
  10. PE_T

    PE_T Road Train Member

    Try waiting a little longer to shift from 4 to 5, or perhaps you need to move a little faster. You have to experiment with it. Are you double clutching or floating gears?

    Bean Jr. and Brettj3876 Thank this.
  11. abyliks

    abyliks Road Train Member

    3,085
    6,901
    May 2, 2010
    ludlow MA
    0
    A 9 and a 13 are the same basic trans, most newer ones will be rtlo models, if it’s an 8LL/8LL over it’s going to be an rto series trans which doesn’t have the “synchro” on the main shaft. But it could have the one on the high/low spitter that is worn out

    PE_T Thanks this.
