Static from LED Headlights

Discussion in 'CB Radio Forum' started by rfevert1963, Jul 26, 2024.

  1. rfevert1963

    rfevert1963 Bobtail Member

    8
    7
    Jan 16, 2019
    0
    Does anyone have a solution to the static noise generated by my darned LED headlights? I have tried resistors which helps with function of the lights but the noise persists. I need to be able to hear because of my line of work avoiding collisions with other trucks on narrow rock roads with limited turn outs. The radio transmits just fine but reception is terrible due to static noise.

    Another Canadian driver and Oxbow Thank this.
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Night Stalker10

    Night Stalker10 Road Train Member

    1,615
    1,205
    Jun 26, 2017
    0
    You can try some RF chokes on the power wire at the LED lights like this guy did.



    You will need to buy these.

    Workman RFC3 4mm Snap Ferrite Core Noise Suppressor RF Choke - Walmart.com

  4. Diesel Dave

    Diesel Dave Last Few of the OUTLAWS

    7,968
    18,583
    Jan 20, 2010
    Hesperia, Ca.
    0
    Are you running a good ground ? Try running the ground from the battery direct. My older Galaxy Pluto radio had a similar issue, but not to noisy. When I replaced it with my Anytone AT 6666, it all went away.

    Another Canadian driver and Oxbow Thank this.
  5. Ridgeline

    Ridgeline Road Train Member

    21,379
    106,954
    Dec 18, 2011
    Michigan
    0
    What type of headlights?

    Are they factory or one of those aftermarket chinese junk?

    Another Canadian driver and Oxbow Thank this.
  6. rfevert1963

    rfevert1963 Bobtail Member

    8
    7
    Jan 16, 2019
    0
    The truck had factory halogen headlights, we purchased the LED lights and resistors through Pete dealer. I don’t recall the name brand but I could actually pick up headlights of other trucks on my cb when I’d meet them on the road, so I made sure these weren’t the noisy ones.

  7. Ridgeline

    Ridgeline Road Train Member

    21,379
    106,954
    Dec 18, 2011
    Michigan
    0
    I won't touch on the legalities of the LED lights in a halogen housing other than they produce a lot of light scatter, but the other part is because they are cheap chinese LED lights that are also illegal because they admit RF that causes the static. The best solution is to run the original lights or a brighter version of it to eliminate the static because these lights are poorly shielded to begin with. you could also try to put a choke on the LED line, it may help, it may even eliminate the problem but overall it may not work at all.

    https://www.amazon.com/RF-Choke-31500-Ferrite-Material/dp/B00XDACVOM/

  8. rfevert1963

    rfevert1963 Bobtail Member

    8
    7
    Jan 16, 2019
    0
    I’m back. So the replacement lamps are fmcsa compliant truck lite heated units. They come stock on the 389 two years younger than my truck. Since 75%of our operation is off highway in fog and snow they are a fantastic upgrade.
    The chokes did the trick.
    Does anybody have a line on a Paccar aftermarket Toyota Prius elimination device? Just kidding! Thanks for the info!

  9. Night Stalker10

    Night Stalker10 Road Train Member

    1,615
    1,205
    Jun 26, 2017
    0
    Good deal, thanks for the update. Glad the chokes worked. It's nice to hear a success story now and then.

    Another Canadian driver and Oxbow Thank this.
  10. Ridgeline

    Ridgeline Road Train Member

    21,379
    106,954
    Dec 18, 2011
    Michigan
    0
    Glad it is working for you.

    There is no such thing. You mean DOT compliant light, it is a pet peeve of mine, sorry.
    You making fun of my Prius?

    Another Canadian driver and Oxbow Thank this.
  11. Diesel Dave

    Diesel Dave Last Few of the OUTLAWS

    7,968
    18,583
    Jan 20, 2010
    Hesperia, Ca.
    0
