2009 Volvo CM871 Vapor locked, need help getting it started.

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by Andystrans, Apr 24, 2024.

  1. Smellfunny

    Smellfunny Road Train Member

    Joined:
    Jan 28, 2012
    Messages:
    1,445
    Thanks Received:
    967
    Location:
    South Carolina
    0
    If you are not getting fuel out of there with the pump running then you are not getting fuel up there. It is either sucking air out of tank or the line has trash in it or the pump is not working.
    Make sure the filters are full of fuel and try again.

    Andystrans Thanks this.
  2. Andystrans

    Andystrans Light Load Member

    Joined:
    Dec 28, 2018
    Messages:
    108
    Thanks Received:
    379
    0
    The filter has fuel, I checked and topped off. When I first removed the filter it still had fuel in it. Any advise on how to check the lines for blockage from the tank to the pump?

  3. Smellfunny

    Smellfunny Road Train Member

    Joined:
    Jan 28, 2012
    Messages:
    1,445
    Thanks Received:
    967
    Location:
    South Carolina
    0
    Where are fuel filters located on truck?

    nikmirbre Thanks this.
  4. Andystrans

    Andystrans Light Load Member

    Joined:
    Dec 28, 2018
    Messages:
    108
    Thanks Received:
    379
    0
    This is an ex swift truck. Only has 1 spin on filter at the pump.

  5. Smellfunny

    Smellfunny Road Train Member

    Joined:
    Jan 28, 2012
    Messages:
    1,445
    Thanks Received:
    967
    Location:
    South Carolina
    0
    You would have to take the line loose at the lift pump and suck and blow on it to test for restriction. And you can suck on the line to see if fuel gets up to that point. Careful when doing this so you don't swallow fuel.

    nikmirbre and Andystrans Thank this.
  6. Andystrans

    Andystrans Light Load Member

    Joined:
    Dec 28, 2018
    Messages:
    108
    Thanks Received:
    379
    0
    Update: Truck is running now.
    Ended up having to pressurize the tanks to get the fuel to the prime pump.

    Used an air compressor via the breather tube to pressurize the passenger tank first. Vice grip pliers to pinch the line.

    Then had a helper push the bleed valve with the prime pump going while adding pressure to the driver tank until fuel started to come out of the bleed valve.

    Had to use starter fluid to spin the motor fast enough and prime the rest of the system.

    Would like to thank everyone who responded.

    Hope this helps someone in the future.
    Pressurizing the tanks is what did it for me.
