Single & Dual Driven Axle Tandem Question

Discussion in 'Trucks [ Eighteen Wheelers ]' started by DBrass, Oct 1, 2014.

  1. Oscar the KW

    Oscar the KW Going Tarpless

    Joined:
    May 19, 2011
    Messages:
    12,247
    Thanks Received:
    28,119
    0
  2. Richter

    Richter Road Train Member

    Joined:
    Feb 13, 2012
    Messages:
    4,090
    Thanks Received:
    1,700
    Location:
    Philadelphia Pa
    0
    then why do single axle trucks still get 300K+ on their tires with the same hp motors?

  3. Hammer166

    Hammer166 Crusty Information Officer

    Joined:
    Aug 18, 2007
    Messages:
    7,560
    Thanks Received:
    27,530
    Location:
    ~8600+' and loving it!
    0
    You happen to have a link to any study that shows that? Because unless you have found the holy grail of tire compounding, more traction load (among other things) will always equal more wear. I can promise you that the higher duty cycle of carhaul, or heavy haul, for examples, generate far higher wear rates than the same tires in line haul. The only way a 6x2 wears the drives at equivalent rates to a 6x4 is with a harder compound tire.

  4. Hammer166

    Hammer166 Crusty Information Officer

    Joined:
    Aug 18, 2007
    Messages:
    7,560
    Thanks Received:
    27,530
    Location:
    ~8600+' and loving it!
    0
    There's also a chart showing the results of a pulling contest on a gravel road in the report.


    Here Richter, I did the leg work for you:


    The same miles per tire, you said? :biggrin_2559:




    http://www.carbonwarroom.com/sites/...ing-Efficiency-6x2-Axle-Confidence-Report.pdf

    Interesting read. Like I said earlier, there are benenfits to 6x2. Better traction isn't one of them. They are a viable solution for guys that don't deal with marginal conditions, and this study shows that you will still save more fuel than you will burn up in tires. If I did nothing but run up and down the big road, I'd jump all over this; but I'd be very hesitant the way I've always operated.

    Cat sdp and Oscar the KW Thank this.
  5. Richter

    Richter Road Train Member

    Joined:
    Feb 13, 2012
    Messages:
    4,090
    Thanks Received:
    1,700
    Location:
    Philadelphia Pa
    0
    run 120 psi and you wont have wear problems

  6. Hammer166

    Hammer166 Crusty Information Officer

    Joined:
    Aug 18, 2007
    Messages:
    7,560
    Thanks Received:
    27,530
    Location:
    ~8600+' and loving it!
    0
    Putting your fingers in you ears and chanting your response repeatedly won't make it any more true!

    Did you even read that link? You're always talking about wanting to learn. That is a very good analysis of 6x4 vs 6x2, that actually concluded that 6x2 is a valid option. I don't suppose you've considered that the fleets with hundreds of 6x2s have tried changing pressure seeking an optimum? And yet they still acknowledge that there is a dramatic difference in tire wear rates?

    I think I'll call Conway's head of maintenance tomorrow:

    "Hey, Richter said you just need to bump the live axle to 120 psi and it will take care of your wear issues."

    "Really?!? That's awesome, we'll start today! I'll be sure and call Michelin and let them know, too! Geez, I can't believe we didn't think of this, give Richter an 'attaboy', wiil ya?"



    Attaboy, Richter, attaboy.



    /sarc

  7. MD48

    MD48 Bobtail Member

    Joined:
    Oct 17, 2014
    Messages:
    3
    Thanks Received:
    2
    0
    Richter I tried 120 lbs all that did was wear the edges on both inside and outside cause of over inflation. The only thing that improved the tire wear some was by going back to dual tires just because you have more foot print on the ground with dual but only 20,000 miles more. The traction was so poor I could break traction on wet pavement on a hill when loaded starting out from a dead stop it's just not a setup that's works for my operation to much weight and to many grades you just can't have tire costs of .05 a mile. If your running lite and on flat ground most of the time it would work.

  8. Davidlee

    Davidlee Medium Load Member

    Joined:
    Aug 31, 2012
    Messages:
    419
    Thanks Received:
    156
    0
    After only a few thousand miles, I can already see a higher than normal wear rate on the drive tires. As for the tag, its almost as if they're not even wearing at all. To Slow the wear rate a little, I have decided to lighten the load on the drive axle by 5%. To offset the higher tire cost, I will run worn down drive tires on the tag axle and regroove as necessary. Hopefull, there will never be a need to ever purchase new tailer tires for the tag axle.
    As for traction, I have been in rain, mud and dirt lots and have yet to see the need to lock the diff or regulate the air pressure on the tag. Certainly, snow and ice will be the ultimate test.

  9. 12 ga

    12 ga THE VIEW FROM MY OFFICE

    Joined:
    Oct 21, 2013
    Messages:
    1,568
    Thanks Received:
    1,789
    Location:
    Central Michigan
    0
    Read my post #25. Here we are on post #49 and you guys are still saying the same thing I said then. You are never going to convince each other he is wrong.

    leftlanetruckin Thanks this.
  10. leftlanetruckin

    leftlanetruckin Road Train Member

    Joined:
    Mar 12, 2009
    Messages:
    3,607
    Thanks Received:
    3,163
    Location:
    Mo Via Blackpool,Lancs.
    0
    Priceless, and so very true....
    How the 2 driven tires on a 6x2 can't wear more than previously being in a 6x4 configuration is beyond me. Same power going through half the tires.....Yep, tire wear!
    Another false saving, besides for VERY few applications.
    Ran them in England in a company truck, would never get them myself except for a lift (read 4th) axle.

    Martin
