Switching from a 48 to 53'

Discussion in 'Flatbed Trucking Forum' started by playamwj12, May 26, 2016.

  1. ChaoSS

    ChaoSS Road Train Member

    Joined:
    Sep 20, 2014
    Messages:
    3,338
    Thanks Received:
    6,757
    0
    I see steps running around all day with 50+ foot loads, they have a few metal braces the height of the step that allow the whole length of the load to sit at the height of the step. That way you can play with long loads just the same as a stupidly heavy flatbed.

    This is one reason I don't like a headboard on the trailer. It eliminates the possibility of hanging stuff over the front of the trailer when you need to move weight forward, or whatever other reason you might have.

  2. snowwy

    snowwy Road Train Member

    Joined:
    Jul 6, 2009
    Messages:
    20,537
    Thanks Received:
    13,274
    0
    I'm curious as to the bridge law on them cali legal spreads. When it came to hauling over 80k. pounds.

    On a standard setup we could max out up to 86k but because of bridge, 84 is the max. Technically speaking. Without special OW permits.

    Them cali legal trailers bring the bridge law down, don't they?

    playamwj12 Thanks this.
  3. Hurst

    Hurst Registered Member

    Joined:
    Aug 24, 2011
    Messages:
    6,618
    Thanks Received:
    12,266
    Location:
    Tampa, Fl
    0

    Ask and you shall receive.

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    .

    My trailer is a 53' 2012 Fontaine Infinity.
    10ft upper deck, 43ft lower deck.
    18" king pin set back. 41.5' kingpin to center axle with the spread open.
    Tare weight of 11,400 lbs.

    Anything else, just ask.

    Hurst

    Last edited: May 30, 2016
  4. TripleSix

    TripleSix God of Roads

    Joined:
    Apr 10, 2009
    Messages:
    18,464
    Thanks Received:
    129,347
    Location:
    Copied in Hell
    0
    This type 53 has lots more useable deck with the longer heavy loads. They do make flats with the same wheel configuration, but what's the point? A 48flat has generally all the deck space you will need. However, if that Malone trailer had this wheelbase instead of the other, that pipe load would have been fine

    playamwj12 Thanks this.
  5. playamwj12

    playamwj12 Heavy Load Member

    Joined:
    Aug 22, 2012
    Messages:
    810
    Thanks Received:
    930
    0
    Thanks for the great information.

    Colorado pulled me across and then backed me back across the scales to check my axles on spread. Leveler is working, and they let the 80 pounds over go. Im.im Rifle CO spending my weekend now.

    In our freight base the 53' will open me up to get 53' truss loads which are light, should be able to get a third sprinter van on there possibly.. And i will start pulling more multi stop aluminum out of Virginia that usually maxes at 44-45K and air conditioners.

  6. MidWest_MacDaddy

    MidWest_MacDaddy Road Train Member

    Joined:
    Feb 21, 2015
    Messages:
    11,151
    Thanks Received:
    18,751
    Location:
    South Carolina
    0
    @Hurst

    Awesome photos... Thanks for sharing them with us... One question, on the back set of axles, there are grooves cut into the trailer but a few photos look like the axles can be set up in between the arches...

    Care to tell me more about how the trailer axles work and adjust? Thank you very much.

  7. Hurst

    Hurst Registered Member

    Joined:
    Aug 24, 2011
    Messages:
    6,618
    Thanks Received:
    12,266
    Location:
    Tampa, Fl
    0

    The rear axle slides. Can be closed and operated as a tandem,.. or spread like you see in the pictures.

    Due to the 41.5' kingpin to center axle length when the axles are spread,.. it is technically not legal in Cali, Ct or Fl. In order to be legal I would need to close the axles to comply with bridge law.

    Florida is the only state to ever hassle me over it. It was only a $75 fine. They allow 44k lbs on tandems,.. I prefer to just keep it spread so I got the annual permit for $20.

    Hurst

  8. ChaoSS

    ChaoSS Road Train Member

    Joined:
    Sep 20, 2014
    Messages:
    3,338
    Thanks Received:
    6,757
    0
    Doesn't that cause issues with weekend and holiday travel? Or do you just close up the tandems for those periods?

  9. 6wheeler

    6wheeler Road Train Member

    Joined:
    Aug 30, 2009
    Messages:
    2,696
    Thanks Received:
    4,774
    0
    Flatbeds Max out on weight in less than 48 feet. I haul 90 percent of all my freight on a 45 foot flatbed. Not unless your going to find some light weight freight, or some 53 foot steel, a 53 foot trailer is not going to bring a good return on investment

    TripleSix and Bean Jr. Thank this.
  10. Hurst

    Hurst Registered Member

    Joined:
    Aug 24, 2011
    Messages:
    6,618
    Thanks Received:
    12,266
    Location:
    Tampa, Fl
    0
    What kind of issues?? Not sure I understand your question.

    I run with my spread open almost every where I go. Almost never close it. I travel weekends and holidays just like any other day unless I'm under an O/S load and in a state with travel restrictions.

    Hurst
