2016 Cascadia sleeper heater core

Discussion in 'Freightliner Forum' started by uncleal13, Dec 22, 2018.

  1. Sanchez392

    Sanchez392 Bobtail Member

    Joined:
    Nov 6, 2019
    Messages:
    3
    Thanks Received:
    2
    0
    How can I bypass the sleeper heater core ?

    truckdriver31 Thanks this.
  2. Sanchez392

    Sanchez392 Bobtail Member

    Joined:
    Nov 6, 2019
    Messages:
    3
    Thanks Received:
    2
    0
    How can I bypass the heater core. Stayed on the side of the road and need to get going

    truckdriver31 Thanks this.
  3. uncleal13

    uncleal13 Road Train Member

    Joined:
    Apr 9, 2009
    Messages:
    3,797
    Thanks Received:
    6,296
    Location:
    Humboldt, Sk
    0
    i used a 3/4" heater hose, long enough to loop back onto the two metal lines just below the heater core above the drivers fuel tank. Unfortunately you may need an extra couple of hose clamps as the two lines are different sizes. The hot side is 3/4", the cold return is 5/8".

  4. Goodie123

    Goodie123 Bobtail Member

    Joined:
    Feb 19, 2022
    Messages:
    5
    Thanks Received:
    1
    0
  5. uncleal13

    uncleal13 Road Train Member

    Joined:
    Apr 9, 2009
    Messages:
    3,797
    Thanks Received:
    6,296
    Location:
    Humboldt, Sk
    0
    No, truck had a valve on the supply side, then I just used vise grips to squeeze shut the hose on the return side.
