2019 D13 injector failure

Discussion in 'Volvo Forum' started by BobO1176, Jan 8, 2023.

  1. ducnut

    ducnut Road Train Member

    Joined:
    Dec 31, 2010
    Messages:
    2,579
    Thanks Received:
    7,766
    Location:
    SPI
    0
    Going down a rabbit hole, now.


    nikmirbre Thanks this.
  2. ducnut

    ducnut Road Train Member

    Joined:
    Dec 31, 2010
    Messages:
    2,579
    Thanks Received:
    7,766
    Location:
    SPI
    0
  3. ducnut

    ducnut Road Train Member

    Joined:
    Dec 31, 2010
    Messages:
    2,579
    Thanks Received:
    7,766
    Location:
    SPI
    0
  4. Siinman

    Siinman Road Train Member

    Joined:
    Mar 5, 2017
    Messages:
    5,291
    Thanks Received:
    13,401
    Location:
    Kansas City, MO.
    0
    What gears and trans do you have in it?

  5. Siinman

    Siinman Road Train Member

    Joined:
    Mar 5, 2017
    Messages:
    5,291
    Thanks Received:
    13,401
    Location:
    Kansas City, MO.
    0
  6. BobO1176

    BobO1176 Light Load Member

    Joined:
    Oct 29, 2021
    Messages:
    139
    Thanks Received:
    202
    0
    i-shift for severe duty, 13 speed crawler, 3.58 ratio. It is the selling feature of the truck, is very good. Let down by engine reliability and low-level interior finishing (has Premier trim) compared to other truck make offerings.

  7. nikmirbre

    nikmirbre Road Train Member

    Joined:
    Jul 27, 2011
    Messages:
    5,432
    Thanks Received:
    9,816
    Location:
    High Point NC
    0
    Curious, what was your symptoms of a baad exhaust valve?

  8. BobO1176

    BobO1176 Light Load Member

    Joined:
    Oct 29, 2021
    Messages:
    139
    Thanks Received:
    202
    0
    Rpm all over the place, loss of power, rough idle. Broke off when I was empty driving back to yard. There might have been an engine code, I can’t recall, this was in June. Service department seemed to know what it was and said ok to keep driving to get home and to the shop.

  9. Siinman

    Siinman Road Train Member

    Joined:
    Mar 5, 2017
    Messages:
    5,291
    Thanks Received:
    13,401
    Location:
    Kansas City, MO.
    0
    Do you often run RPM over 1400 with those gears? Seems to stop the emissions issues, cups and injectors you have to run around 1250-1350 max on these newer D13 Engines.

    BobO1176 Thanks this.
  10. nasriza

    nasriza Road Train Member

    Joined:
    Feb 1, 2013
    Messages:
    2,397
    Thanks Received:
    2,070
    Location:
    Chicago, IL
    0
    usually the most issues i see is in 500hp trucks, can never really point to why this is, whoever charged you $11000 for injector to me this is highway robbery. Max i could see from a dealer would be about $7500, either way. I have seen broken valves and I have see injectors failure but by far yours is the lowest mile one. it has nothing to really do with fuel being to dry although it doesn't help, they do last longer than old style volvo injectors. I have also seen my fair share of liner leaks mainly under warranty repair but definitely lower quality than previous years as far as build goes.

    ducnut and Siinman Thank this.
