2021 Peterbilt 389 Vibration

Discussion in 'Peterbilt Forum' started by Sukhjiwan3, Oct 30, 2022.

  1. Sukhjiwan3

    Sukhjiwan3 Bobtail Member

    8
    5
    Oct 30, 2022
    0
    Hello,
    I am across some interesting helpful threads here and I thought I can get some help for the community here.
    My issue has been from day 1 of buying the brand new 2021 Pete 2 years back. When I first got it there was major shaking, my gallon of water would shake and spill 1/4 of the gallon if I didn’t have the cap on. It was really bad and I took to peterbilt and they denied the truck had any problems. It went to the dealership twice back when I bought it and both times they changed the ride height and check angles and say it fine. I gave up after arguing with the dealership and took it a private major shop that does collision work and driveline. They found one of rear tires was out of round but all my rims were good, and they found the truck driveline angles was off but otherwise it looked good. We went ahead and fixed all angles to spec and replaced that tire. I noticed a difference up to 50% less vibration. But I still have a constant vibration at all speeds above 40, you feel it more when going up hill, even on a smooth ride in neutral or in gear it still has a vibration. After 11 hours of driving as you can imagine it like your on a vibration machine but instead my whole body is tired. We have checked yokes alignment and u joints, everything checked out. We even got the meritor driveline balanced which helped a little. But the issue is still there, constant vibration, gallon of water still shakes a lot. I can’t figure it out for the life of me, please suggest ideas. Any shops you guys recommend in northern Cali or hell anywhere close to Cali, let me know! It’s beautiful 389 with all the bells and whistles, I don’t wanna go back to a Volvo lol

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Sukhjiwan3

    Sukhjiwan3 Bobtail Member

    8
    5
    Oct 30, 2022
    0
    Also one thing is my rear driveline shaft(small one to the rear axle) has awkward angle from the ujoint. I looked at other with 24.5 tires and they look the same and angle dealership says is right. also I don’t know why my truck only has 1 carrier bearing. All other Pete have 2 carrier bearings. For reference look at the drawing I quickly drew up.
    A little about specs:
    2050 torque
    565hp Cummins
    24.5 tires
    Meritor driveline


    Attached Files:

  4. Siinman

    Siinman Road Train Member

    2,774
    6,119
    Mar 5, 2017
    Kansas City, MO.
    0
    Love my 23 VNL 860. It hardly makes any noise and has one of the best rides a person could ask for. Glad I did not try and be cool like the (REAL TRUCKERS) and got a good truck. Good luck with that rattle trap. On another note if you can find a
    MD Alignment shop they may be able to help you out. Good luck!

  5. Sukhjiwan3

    Sukhjiwan3 Bobtail Member

    8
    5
    Oct 30, 2022
    0
    I had new 2013 780 a Volvo before this and I loved it drove it for almost a million miles! I just like Peterbilt look and old school style a little better, nothing against Volvo. I might have to get a new Volvo if I can’t figure this issue out. Let me know if any one has suggestive shops for driveline or vibration experts

    Siinman Thanks this.
  6. Siinman

    Siinman Road Train Member

    2,774
    6,119
    Mar 5, 2017
    Kansas City, MO.
    0
    MD Alignment Services - Makers of MD Alignment QCT Alignment Systems Check out some of these guys. This would be one of the first places I would look for. Chad in Kansas City MO is top notch but you are in cali.

  7. Brandt

    Brandt Road Train Member

    3,787
    4,842
    Sep 17, 2012
    0
    Don't know what's wrong but I was going to say if you could go see Chad in Kansas City also he could probably find it. Maybe you can put truck on Dyno and find what's wrong. You could call MD alignment radio show and ask them. Could be out of balance brake drums if you have drum brakes. Could be brake drums are not centered on wheel axles.

    Try calling in the the podcast and asking MD alignment guys. Rolling Toe
    AudioRoad Network

  8. Josiah Harder

    Josiah Harder Bobtail Member

    35
    18
    Sep 23, 2022
    0
    My dad had to get the drive shaft in his Ford rebalanced recently it was causing a vibration like you describe. A slight imbalance can cause problems maybe that's your issue too. If it was like that from the beginning that must be manufacturer defect and covered on warranty. I have a 2019 389 and my driveline is exactly like your picture. I only have 1 carrier bearing and 3rd piece is at an angle

  9. Sukhjiwan3

    Sukhjiwan3 Bobtail Member

    8
    5
    Oct 30, 2022
    0
    Siinman Thanks this.
  10. Sukhjiwan3

    Sukhjiwan3 Bobtail Member

    8
    5
    Oct 30, 2022
    0
    Is Chad a person who works for MD alignment? sorry I don’t know. If Chad is really the top expert I’ll take it Kansas City no problem. I’ll do anything to find out the cause.
    Also I have disc breaks all around; no drums so that can’t be a issue. I don’t have a dyno around here if you guys know of any shop that does dyno, let me know!
