air tank fitting

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by 4noReason, Aug 17, 2022.

  1. 4noReason

    4noReason Road Train Member

    2,327
    698
    Nov 29, 2012
    0
    hey guys can anyone guide me to where i can buy a air tank fitting online. It looks likeca 1/4 straight fitting. 2016 freightliner columbia. Its leaking air. 20220817_184105.jpg

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. kwswan

    kwswan Road Train Member

    1,632
    8,042
    Jul 26, 2009
    mcminnville,tn.
    0
    McMaster Carr or go to a napa or Carquest local & get it without waiting.
    Replace it with a compression fitting instead of the push lock.

    86scotty, D.Tibbitt, 4noReason and 4 others Thank this.
  4. D.Tibbitt

    D.Tibbitt Road Train Member

    17,084
    111,821
    Apr 26, 2013
    Gettin' down westbound
    0
    It looks like a threaded quick connect. Can buy them anywhere. Amazon probably cheapest if u can wait for delivery.. If not , try fleet pride or dealership.. Get the brass quick connect while ur at it. The plastic ones always leak eventually

    4noReason, Rideandrepair and JonJon78 Thank this.
  5. BoxCarKidd

    BoxCarKidd Road Train Member

    3,870
    5,507
    Aug 26, 2014
    0
    I agree. The ones from the hardware store for plumbling are not DOT approved.
    The first trucks I heard of with push to connects were 9 story Fords. There was a campain to replace all of those fittings. Man worked on that for about three weeks. Finished that and asked what is next. Well you did such a great job there is another one parked by the fence. His expression said he must have been pretty close to vested for retirement as he began again.
    Those fittings are better now but I am slow to for give. Same with the first push in wheel seals. I only use them if that is the only thing available.

  6. Rideandrepair

    Rideandrepair Road Train Member

    14,585
    48,456
    Aug 8, 2015
    0
    The Parker store has an excellent selection of individual fittings. No sure about price, they said no charge. I had about 5 different fitting sizes. Best to have some extra ferules. Dealer has the good ones, with the raised ridge around the outside. They fit nicely. An assortment of quick connects is nice to have for an emergency. The ones to really have are the 2 sizes that can splice an airline. Not the quick connect, but brass w/ ferules. Along with 3’ of each size. Cheap kit to keep, might come in handy someday at a Scalehouse, shutdown for a minor chafed air line, just cut and connect, making an in-line splice. Trailer air lines dragging? No problem. Lol.

    D.Tibbitt and 4noReason Thank this.
  7. 4noReason

    4noReason Road Train Member

    2,327
    698
    Nov 29, 2012
    0
  8. Ridgeline

    Ridgeline Road Train Member

    18,634
    85,430
    Dec 18, 2011
    Michigan
    0
    Please don’t be cheap with your fittings, get dot “approved” fittings from NAPA or from Parker. Replace the push on with one that uses an insert and a ferrel, you won’t have a problem with a leak later on.

    4noReason Thanks this.
  9. RocketScott

    RocketScott Medium Load Member

    488
    705
    Apr 10, 2013
    Kentucky
    0
    Wouldn't be a bad idea to put a 45 on it

    That hose has a pretty good bend in it

    4noReason and krupa530 Thank this.
  10. IH Truck Guy

    IH Truck Guy Road Train Member

    2,506
    27,328
    Mar 2, 2008
    Purgatory
    0
