BC400 to N14?

Discussion in 'Ask An Owner Operator' started by Marmon110P, Nov 25, 2022.

  1. Marmon110P

    Marmon110P Light Load Member

    136
    137
    Feb 24, 2019
    0
    Hey fella's, Ive got an 84 Marmon with a BC400 and Ive been seeing alot on the N14 upgrade parts to crank more power out of it. Can a guy possibly convert this BC to an N14 since I assume the block n guts are the same?

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. 062

    062 Road Train Member

    5,517
    20,860
    Oct 20, 2013
    0
  4. OLDSKOOLERnWV

    OLDSKOOLERnWV Captain Redbeard

    14,610
    220,261
    Nov 29, 2011
    West Virginia
    0
    Although the Big Cam & N14 share the same cubic inches ( bore / stroke), the N14 crankshaft will not fit directly into a Big Cam block, it takes machine work to make that happen.

    I have converted an early 90’s N14 electronic engine to fully mechanical using Big Cam parts, but that too takes machine work as well as the .010 thicker head gasket for valve clearance….

    SL3406, beastr123 and 062 Thank this.
  5. OLDSKOOLERnWV

    OLDSKOOLERnWV Captain Redbeard

    14,610
    220,261
    Nov 29, 2011
    West Virginia
    0
    Many ask about using a N14 2 piece steel top piston in a Big Cam, that will not work as a direct fit since the 2 engines have a different size wrist pin. And the N14 has a larger rod journal….

    Bean Jr., SL3406 and 062 Thank this.
  6. Marmon110P

    Marmon110P Light Load Member

    136
    137
    Feb 24, 2019
    0
    Hmm...OK well that definitely answers my question then...its a hard NO! By adding an N14 HT60 turbo, air to air and intake to these what kinda power could I expect to gain? Ive seen 100HP, but I dont know if thats realistic.

  7. OLDSKOOLERnWV

    OLDSKOOLERnWV Captain Redbeard

    14,610
    220,261
    Nov 29, 2011
    West Virginia
    0
    As far as the ( air to air ) goes, don’t expect any horsepower gains at all that are detectable without a dyno.

    I’ve been running air to air on my Big Cam 400 for 6 years or so.
    I can say there is a minimal difference in the egt’s, but nothing else that is really detected during normal driving.

    It you want to give it a little extra zip, send the pump to Premco in Texas, let Warren build you a matching set of injectors to the pump he builds for you. Tell him what turbo you have and the CPL number so he can synchronize the pump and injectors to the engine.

    Or….. you can just crank the fuel pressure up with the pump you have now, and just replace the camshaft at a later date when the injector lobes start flaking from the added pressure…..


    Bean Jr. and SL3406 Thank this.
