C15 front cover

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by BoxCarKidd, Oct 9, 2018.

  1. Oct 9, 2018 #1
    BoxCarKidd

    BoxCarKidd Road Train Member

    4,551
    6,641
    Aug 26, 2014
    0
    Have a few Cats hanging around here. One has a crack in the front cover. It is in front of the idler that runs the fuel pump and air compressor. Did not thank we would need a book for a front cover job but stopped when we did not find timing marks on the gears. Would really like to pull it down and inspect before a book and front cover show up. Any info appreciated. KIMG1213.jpeg KIMG1212.jpeg

    BoxCarKidd, Oct 9, 2018
    BoxCarKidd, Oct 9, 2018
    #1
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Oct 10, 2018 #2
    spsauerland

    spsauerland Road Train Member

    4,296
    10,891
    May 31, 2010
    West Harrison, In
    0
    Uploaded the gear install and backlash procedure so you can start. Timing marks are on crank gear, cluster gear, cam gear and front housing. I would bar engine to TDC #1 and look @ timing mark between cam gear and housing. May not line up dead on so you know if half tooth left or right. Torque not listed in disassembly/assembly use generic Cat torque chart.


    Attached Files:

    spsauerland, Oct 10, 2018
    spsauerland, Oct 10, 2018
    #2
    SAR, pushbroom, swaan and 1 other person Thank this.
