Chain size 5/16 or 3/8?

Discussion in 'Flatbed Trucking Forum' started by randypinenc, Apr 7, 2020.

  1. randypinenc

    randypinenc Light Load Member

    59
    50
    Apr 21, 2018
    0
    I’ll be hauling a variety of freight and at times that will include steel. I understand WLLs. My question is, I have a good opportunity to purchased a slightly used “flatbed kit.” It contains lumber tarps, coil tarps, ratchet binders, lots of useable stuff. I’m concerned about the chain size though. This kit includes 5/16 chain. Can those chains be (or should they be instead of 3/8) used on loads of steel, coils, I-beams, etc? Or is it simply a matter of more chains to meet the WLL?

    cke and PoleCrusher Thank this.
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Hegemeister

    Hegemeister Road Train Member

    1,912
    1,660
    Jun 16, 2012
    Mechanicsburg, PA
    0
    Perfectly legal if you meet WLL. My concern would be all the extra work having to use more chains over and over. I would definately go with 3/8 inch. It will be much less work in the long run.

    Also think about hauling vehicles. With the larger chain your more likely to only have to secure 4 corners as opposed to needing to secure 6 points.

  4. brsims

    brsims Road Train Member

    5,295
    6,513
    Aug 8, 2009
    Meadville, PA
    0
    5/16ths is perfectly legal as long as it is Grade 70 (G70, transport chain). I used it in steel haul. Yes, you throw a few more chains. Bit 5/16ths is considerably lighter than 3/8ths, so it's a wash in the end.

    Oil the ever loving heck out of the ratchet binders. I've had really good luck with 2-cycle engine oil. And check the tarps VERY carefully for pinholes. Repair those quick quick, cause small hole turn into big holes fast.

    Good luck!

  5. PoleCrusher

    PoleCrusher Road Train Member

    7,503
    82,189
    Aug 26, 2014
    LLMF
    0
    Yeah it's just a matter of preference. Unless you're gonna be hauling a lot of heavy stuff where throwing the extra chains would be too time consuming. As long as they're G70 and you meet WLL, 5/16 is fine.

    Tug Toy, Diesel Dave, SAR and 3 others Thank this.
  6. Bean Jr.

    Bean Jr. Road Train Member

    5,338
    9,357
    Mar 30, 2014
    0
    I haul steel and use 3/8". I calculated what I would use if I had 5/16" 70 grade. WLL is 4,700 vs 6,600 for 3/8". 45,000 lb coil, I am required by my carrier to use 7 tiecdowns. 1 set of cross chains, 3 sets of u chains and 1 strap over the top. Cumulative WLL must be at least 22,500, so 2 cross chains is 9,400 WLL, 3 sets of u chains is 14,100 WLL (indirect tiedown to the same side is 50% of WLL) and 5,400 lb 3" ratchet strap is a total of 28,500 lbs. In this case there is no need to throw additional chains to make up for the loss in WLL.

  7. BackwoodsGA

    BackwoodsGA Road Train Member

    1,872
    9,334
    Mar 18, 2012
    Elgin Nd
    0
    I prefer 3/8 chains.Less work.

  8. Tug Toy

    Tug Toy Road Train Member

    6,787
    70,666
    Jul 4, 2015
    Corn field
    0
    No reason to haul 3/8 chain around of your trailer attachment points are only good for 5500lb?

  9. cke

    cke Road Train Member

    5,394
    66,175
    Aug 4, 2013
    Colfax Wi
    0
    Very good point

    Bean Jr., randypinenc and SAR Thank this.
  10. cke

    cke Road Train Member

    5,394
    66,175
    Aug 4, 2013
    Colfax Wi
    0
    1ACF3654-697C-40B5-8A10-6754EEBD619F.jpeg Some kind of inferno burger from Gronks Bar and Grill.

  11. Hegemeister

    Hegemeister Road Train Member

    1,912
    1,660
    Jun 16, 2012
    Mechanicsburg, PA
    0
    Drink the beer first.
