Cummins N14 no start

Checked everything over wiring is good. New harness from Cummins. Tried to start it for the first time. No start, tons of white smoke.

Last time I had this issue I replaced the Cam sensor.

Waiting on places to be open on Monday but I wanted to see what others think as well.

No power to fuel Solenoid either. I'm guessing with this ecm it needs the Cam sensor to send its position to start firing at the right time as well as sending fuel through the injectors?



PS checked fuses at the battery and both are good.



2000 Freightliner Classic. The only wires I've seen with fuses are on the positive wires going to the batteries.

No codes. I do get a stop Engine code with the fuel Solenoid jumped from the battery to solenoid.



That's what I thought as well. Reading back to how these were engines originally designed its got me really wondering and hitting my head against the wall.

Originally the power was only going to the solenoid after the Cam sensor hit the right position, then sent that to the ecm.



Yes, it was hooked up. Took it off after just to test to make sure it was reading on the ecm.



Do you know if the location of the fused lines matter on the positive battery terminals?

I have them how u thought they were originally but I'm going to stick them together on the same post and see what happens.
