T660 ride height

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by insanityeight, Sep 2, 2018.

  1. Sep 2, 2018 #1
    insanityeight

    insanityeight Light Load Member

    291
    113
    Jul 26, 2013
    birmingham al
    0
    Looking for proper ride height on 4 bag kw t660 2014 model. Can i change it any if its already correct cos it rides rough

    insanityeight, Sep 2, 2018
    insanityeight, Sep 2, 2018
    #1
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Sep 2, 2018 #2
    spsauerland

    spsauerland Road Train Member

    4,296
    10,891
    May 31, 2010
    West Harrison, In
    0
    8.75" unloaded. Ride height is for proper u-joint working angles, not ride comfort. Check shocks, cab ride height,or cab shocks?

    spsauerland, Sep 2, 2018
    spsauerland, Sep 2, 2018
    #2
    pushbroom and SAR Thank this.
  4. Sep 2, 2018 #3
    insanityeight

    insanityeight Light Load Member

    291
    113
    Jul 26, 2013
    birmingham al
    0
    It was set nearly on 10. Lowered it and omg it rides better and is now correct. Thanks

    insanityeight, Sep 2, 2018
    insanityeight, Sep 2, 2018
    #3
    bbechtel16 and spsauerland Thank this.
  6. Sep 10, 2019 #5
    OneLowT660

    OneLowT660 Bobtail Member

    1
    0
    Sep 10, 2019
    0
    How di you measured this height from floor to wear

    OneLowT660, Sep 10, 2019
    OneLowT660, Sep 10, 2019
    #5
  8. Sep 10, 2019 #5
    Goodysnap

    Goodysnap Road Train Member

    3,748
    9,115
    Jul 12, 2017
    0
    measurement is from axle center to bottom of frame when aired up at height.

    If easier, measure axle center to ground , measure frame to ground and subtract the two

    Goodysnap, Sep 10, 2019
    Goodysnap, Sep 10, 2019
    #5
    spsauerland and pushbroom Thank this.
  9. Sep 29, 2021 #6
    bordeaux

    bordeaux Bobtail Member

    9
    8
    Nov 9, 2017
    0
    Dude how do you lower it ?

    bordeaux, Sep 29, 2021
    bordeaux, Sep 29, 2021
    #6
  10. Sep 29, 2021 #7
    Goodysnap

    Goodysnap Road Train Member

    3,748
    9,115
    Jul 12, 2017
    0
    Adjustment is made at the leveling valve mounting. Loosen the nuts, the mounting bracket is slotted.

    Goodysnap, Sep 29, 2021
    Goodysnap, Sep 29, 2021
    #7
    bordeaux Thanks this.
