Trailer brakes smoking

Discussion in 'Ask An Owner Operator' started by Truckerjay23, Sep 6, 2021.

  1. Truckerjay23

    Truckerjay23 Bobtail Member

    1
    0
    Sep 6, 2021
    0
    I have a 05 century, I’m having a problem with every trailer i pull. It either smokes the tires or lock them up. I changed out everything but the compressor. Need help

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Cattleman84

    Cattleman84 Road Train Member

    7,233
    40,536
    Nov 1, 2017
    The Sticks, Idaho
    0
    Sure your not hooking up the air lines backwards?

    feldsforever Thanks this.
  4. baha

    baha Road Train Member

    3,830
    2,400
    Jul 25, 2013
    ga
    0
    Does the pigtail have power to the trailer brake anti/lock ?

    feldsforever Thanks this.
  5. Old Man

    Old Man Road Train Member

    4,310
    11,708
    Apr 3, 2009
    Oklahoma City, OK
    0
    Maybe your truck brakes are crap and the trailer is doing all the stopping.

  6. sealevel

    sealevel Road Train Member

    2,498
    8,694
    May 31, 2012
    U.S. 41
    0
    Gotta be some valve applying too much air to the wrong place on the tractor. @Hammer166 is a encyclopedia on such things.

    feldsforever and Hammer166 Thank this.
  7. AModelCat

    AModelCat Road Train Member

    22,495
    106,386
    Jul 7, 2015
    Canuckistan
    0
    Go out to the truck. Build air to cutout and shut off the truck. Leave the park brakes set. Step on the brake pedal about 1/2 way and release. Go out and immediately disconnect the service (blue) gladhand. Let us know if there's air in the line or not.

  8. truckdriver31

    truckdriver31 Road Train Member

    6,505
    7,603
    Sep 18, 2013
    0
    stop riding your brakes.

    Happily Retired Thanks this.
  9. Hammer166

    Hammer166 Crusty Information Officer

    5,581
    17,340
    Aug 18, 2007
    ~8600+' and loving it!
    0
    Everything? That's a lot of parts...


    3 quick possibilities come to mind.

    1. As @Old Man suggested, are the truck brakes doing their share of the work?

    2. The foot brake valve is fubar'd and dumping full pressure in one circuit. That would also be hitting the steer axle brakes hard.

    3. I suppose it's possible something screw ball is happening in the Tractor protection valve, but I'm not seeing how it could. There's definitely service and supply in that same valve though.

    We really need to know what was changed, though.

    feldsforever and sealevel Thank this.
  10. truckdriver31

    truckdriver31 Road Train Member

    6,505
    7,603
    Sep 18, 2013
    0
  11. Jacoooooooo

    Jacoooooooo Medium Load Member

    463
    446
    Oct 20, 2013
    0
    Time for a new truck.
    Just maybe.

    feldsforever Thanks this.
