Where is everyone #5

It’s not every day I get to work on a pic of a truck with that much cool.



Two transmissions. The way modern 13/18 have a front and back half with buttons, used to have to do that with a shifter.



No, numerically you would multiply the 5 by 4 for 20 speeds, but there was a lot of overlap and different possibilities that could be used, so you didn't end up with 20. It had a 5 speed main box with reverse, and then a 4 speed brownie, or auxiliary. This particular one had an overdrive in both the main and brownie.



Hey @wore out , when you get a chance, could you please answer a couple of questions? I wasn't going to bore everybody with this and was going to send you a PM, but I can't attach files via a PM, so here goes. Which spring were you talking about replacing with the purple stripe spring and washer on my 4mg, is it number 13 in the first pdf? Or one of the ones in the second?

Also, you had talked about the potential of using 8785 nozzles, but had to check to see if they were compatible with my pistons. I have 8N-1608 pistons.

Thanks!



Did y’all know that, when that Oklahoma wind comes sweeping down the plains, THIS will wake you up from a dead sleep?



I guess the black sticky tape let go from all but one corner.



It's the first spring on governor when you pull back off pump. That first pic shows the spring (13) in front of the one I'm talking about.

I have been needing that timing advance break down just kept forgetting to ask you for it.


Yes the 8785 will work with those pistons



I be bustin tail to go back home... got 5 of these suckers to do! Just got back from the blasters.



Thank you sir!



Here are the part numbers for the advance picture if it helps.





1 7W-0993 1
GEAR-PUMP DRIVE
(64-TEETH)

2 7W-3218 1
RING-GUIDE

3 7W-5242 1
CARRIER-DRIVE

4 7C-5902 1
BODY AS

7C-5892 1
BUSHING-TERMINAL

7C-5894 1
BODY

7C-5900 1
SLEEVE

7M-5839 1
PLUG-CUP

5 8F-1145 1
RING-LOCK

6 4W-0436 1
SEAL-QUAD RING

7 6V-7698 4
BOLT
(1/4-20X3.25-IN)

8 1B-4427 4
NUT-JAM
(1/4-20-THD)

9 4W-2754 2
SEAL-QUAD RING

10 4W-7751 1
CARRIER-WEIGHT

11 1S-5440 4
DOWEL

12 7N-7264 4
WEIGHT-GOVERNOR

13 7C-9219 1
SPRING

14 3K-3467 1
NUT
(7/8-20-THD)

180-0035 1
NUT

15 7W-7663 1
SCREW-ADJUSTMENT

16 5H-6552 1
SETSCREW-SOCKET
(10-32X1.25-IN)

17 8L-5832 1
NUT-HEX
(10-32-THD)

18 8C-9034 4
BOLT
(10-24X1-IN)

19 8S-7803 1
RING-RETAINING

20 4N-2927 1
RACE-THRUST BEARING

21 9Y-7450 2
RETAINER

22 4W-7752 1
SPOOL

23 7W-1527 1
RETAINER

24 2W-9952 1
PLATE

25 0T-0065 4
BOLT
(3/8-16X3.5-IN)

26 7W-5241 1
RING-DRIVE


4W-8333 DRIVE GP-GOVERNOR & FUEL PUMP
S/N 4MG3600-57673">
Copyright 1993 - 2019 Caterpillar Inc.
All Rights Reserved.
Private Network For SIS Licensees.
Thu Jul 04 2019 10:38:56 GMT-0600 (Mountain Daylight Time)
