Urgent help: in cab airline!

Discussion in 'Questions From New Drivers' started by Penumbra, Jan 23, 2020.

  1. Penumbra

    Penumbra Light Load Member

    247
    440
    Jul 29, 2019
    0
    So! For some reason after multiple months my genius dog decided that chewing on the airline under my seat seemed like a good idea

    I’ve taped where the leak is, but it’s not working, tons of air leaking out. What do I do?!?

    I just need a quick fix hat that’ll last a few days until I can get home


    Attached Files:

    blairandgretchen Thanks this.
  2. sirjeff

    sirjeff Medium Load Member

    332
    905
    Dec 1, 2013
    Kelowna, BC
    0
    Vice grips will work best

    Or cut the line and fold it over itself so it pinches and tape around the fold

    Or go pick up a couple ferrals from a repair shop (the little brass pinch inserts inside that t fitting) take it apart and cut off the section of damaged line and refit. Will cost you maybe $1 and take 5 mins if you have a couple wrenches

  3. Cabinover101

    Cabinover101 Medium Load Member

    668
    982
    Jul 28, 2019
    0
    What he said ^^^^ Cut out the bad part, undo the nut where your air gun is spliced in and replace the ferrals, bolt back together.

    rachi and blairandgretchen Thank this.
  4. blairandgretchen

    blairandgretchen Road Train Member

    8,263
    35,578
    Dec 9, 2011
    South west Missouri
    0
    Vice grips, or pinch, bend, fold and tape - anything to stem the flow.

    Any Napa or O’reillys should have fittings to repair. You’ll need 1/2” and 9/16” wrenches from memory for the brass fittings.

  5. flybynight12

    flybynight12 Medium Load Member

    578
    417
    Jan 10, 2015
    slc
    0
    Flex seal they cut a boat in half

    birdman52, Hazmat Cat and Cabinover101 Thank this.
  6. Penumbra

    Penumbra Light Load Member

    247
    440
    Jul 29, 2019
    0
    Ok so the leak has been temporarily dealt with. The entire brass fitting was going so I essentially cut the gun out and taped up both ends until I can get to a shop.

    however that also killed the air for my seat so I’m pretty much sitting on the floor

  7. Cabinover101

    Cabinover101 Medium Load Member

    668
    982
    Jul 28, 2019
    0
  8. Penumbra

    Penumbra Light Load Member

    247
    440
    Jul 29, 2019
    0
    Yep...yes indeed here’s my eve level...


    Attached Files:

  9. Cabinover101

    Cabinover101 Medium Load Member

    668
    982
    Jul 28, 2019
    0
    Be Careful
