2009 international prostar with isx cummins fault codes

Discussion in 'International Forum' started by jasonpanro, Sep 1, 2013.

  1. josglo

    josglo Bobtail Member

    Joined:
    May 26, 2017
    Messages:
    1
    Thanks Received:
    0
    0
    On my 2010 international prostar with isx cummins motor, my traction control light is on and it says abs module. Also, a yellow triangle pops up, alongside a red octagon and an exclamation mark. My truck just goes right away to idle. It doesn't matter if I am traveling 70 MPH. I need to put it in neutral and the only way that the RPs go up is when it's in neutral and I press the gas peddle. I kick to 1100 RPM. Then as soon as the needle on the RPM gauge goes down to idle position, all of the the lights disapear and my truck is ready to roll again. Thank you for your time.

  2. QUALITYTRUCK

    QUALITYTRUCK Road Train Member

    Joined:
    Jun 14, 2009
    Messages:
    1,804
    Thanks Received:
    1,765
    Location:
    romulus,mi
    0
    Need to have diagnosis with Insite to have better chance for proper repair. Sounds like a break in J1939 data link wires which is how all modules communicate with each other.

  3. Heavyd

    Heavyd Road Train Member

    Joined:
    Feb 4, 2009
    Messages:
    7,767
    Thanks Received:
    6,204
    0
    Certain throttle pedal codes can cause both yellow and red warning lights and limit throttle rpms and this is also tied into the ABS system, but like Qualitytruck said, you really have to get it scanned and properly troubleshot. Not a whole lot we can do for you here.
