Air pressure in secondary line won't go up to normal level

Discussion in 'Freightliner Forum' started by expedite_it, Sep 13, 2024.

  1. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    When I was driving to the truckstop, I thought that maybe the air compressor on the truck is defective. But now I don't think that the air compressor is defective. If the air compressor was defective, I don't think the primary air line would have 120 psi with the engine turned off.

    I think you are right that there is a leak of some kind.

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    @Rideandrepair
    @Ridgeline
    Does anyone have any idea as to why the air pressure in both the primary and secondary air lines rose almost to normal pressures when I idled the truck engine for about two or three minutes to microwave food last night?

    The mechanics have not worked on the truck yet. I don't get it. I am baffled.

    Last edited: Sep 14, 2024
  4. Ridgeline

    Ridgeline Road Train Member

    22,365
    115,987
    Dec 18, 2011
    Michigan
    0
    It is obvious … you have an air leak, maybe simple to find.

  5. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    About 4 days ago, I accidentally drove my semi-truck all day with the air bags dumped. Do you think that my driving with the air bags dumped all day could have caused the leak?

    @Ridgeline
    @Rideandrepair

    Last edited: Sep 14, 2024
  6. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    The photograph above is a photograph that I took of my truck about an hour ago. The air pressure in the secondary dropped overnight to 25 psi.

    I found the photograph below this sentence on my cell phone. The photograph below is a photograph of a different Freightliner truck than the Freightliner truck I have now. On this Freightliner truck four years ago, both the primary and the secondary air pressures were at about 120 psi with the engine off. I think that is how my current truck would normally be with the engine off.
    ---------------
    So the two photographs on this post are photographs of two different trucks, but both of the trucks are Freightliner Cascadias.

    Last edited: Sep 14, 2024
  7. SmallPackage

    SmallPackage Road Train Member

    5,441
    17,249
    Dec 20, 2019
    Marion Texas
    0
    Yes. If an air spring was damaged and has a slow leak it will bring the secondary side down. Pretty good in 10 years you’ e only done that once. Lol.

    Rideandrepair Thanks this.
  8. North Pole Nightmare

    North Pole Nightmare Heavy Load Member

    846
    1,641
    Dec 15, 2021
    0
    Dump your suspension switch if you have one,if the pressure goes back to normal then your suspension has a leak.If you don't have the dump switch you can chock the wheels ,release the brakes,and look for the leak.

    expedite_it Thanks this.
  9. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    I do have a suspension switch.

    I'm assuming "dump your suspension switch" means dump the air bags. I suppose I should perform that test with the truck parked and the engine idling; correct?

  10. North Pole Nightmare

    North Pole Nightmare Heavy Load Member

    846
    1,641
    Dec 15, 2021
    0
    Yes

    expedite_it Thanks this.
  11. expedite_it

    expedite_it Road Train Member

    1,646
    863
    Sep 8, 2012
    0
    If the pressure does not go back to normal when i dump my air bags, what does that indicate? Where would my leak be then?
